2000 (390-900Kw) Diesel Engine
Technical Specification of 2000 Diesel Engine:
| Model | Rated power (kW) |
Rated rpm (r/min) |
Fuel consumption (g/kw.h) | Oil consumption (g/kw.h) | Overall dimensions (mm) |
Net weight (kg) |
| G12V190ZL1 | 1000 | 1500 | 209.4 | ≤1.6 | 2692x1560x2070 | 5300 |
| G12V190PZL1 | 4301x1980x2678 | 8100 | ||||
| G12V190ZL-3 | 810 | 1300 | 2692x1560x2070 | 5300 | ||
| G12V190PZL-3 | 4301x1980x2678 | 8100 | ||||
| G12V190ZL-1 | 740 | 1200 | 2692x1560x2070 | 5300 | ||
| G12V190PZL-1 | 4301x1980x2678 | 8100 | ||||
| G12V190ZL-2 | 600 | 1000 | 2692x1560x2070 | 5300 | ||
| G12V190PZL-2 | 4301x1980x2678 | 8100 | ||||
| G8V190ZL | 600 | 1500 | 213.5 | ≤2.7 | 2112x1560x2080 | 4300 |
| G8V190PZL | 3950x1980x2678 | 6750 | ||||
| G8V190ZL-3 | 510 | 1300 | 2112x1560x2080 | 4300 | ||
| G8V190PZL-3 | 3950x1980x2678 | 6750 | ||||
| G8V190ZL-1 | 470 | 1200 | 2112x1560x2080 | 4300 | ||
| G8V190PZL-1 | 3950x1980x2678 | 6750 | ||||
| G8V190ZL-2 | 390 | 1000 | 2112x1560x2080 | 4300 | ||
| G8V190PZL-2 | 3950x1980x2678 | 6750 |
Technical Parameters
| Structure type | 4-stroke, direct injection combustion chamber, water-cooled, exhaust gas turbocharged, inlet air inter cooling |
| Number and arrangement of cylinders | 12, 8-cylinder, V shape, 60°angle |
| Diameter of cylinders(mm) | 190 |
| Stroke(mm) | 210 |
| Total displacement(L) | 71.45/47.6 |
| Compression ratio | 14:1 |
| Exhaust temperature() | ≤600 |
| Outlet temperature() | ≤90 |
| Oil temperature(oil sump,) | ≤95 |
| Steady speed change ratio (%) | ≤8(generator sets≤5) |
| Cooling mode | Pressurized water cooling |
| Lubrication mode | Press and spray lubrication |
| Starting mode | Air motor or electric motor starting |
