Specification of B3000 Diesel Engine:
| Model | Rated power (kW) |
Rated rpm (r/min) |
Fuel consumption (g/kw.h) | Oil consumption (g/kw.h) |
Overall dimensions (mm) |
Net weight (kg) |
| BH12V190ZL | 1360 | 1500 | 202 | ≤1.0 | 2950x2280x2069 | 9300 |
| BH12V190PZL | 4189x2345x2636 | 11000 | ||||
| BH12V190ZL-3 | 1210 | 1300 | 2950x2280x2069 | 9300 | ||
| BH12V190PZL-3 | 4189x2345x2636 | 11000 | ||||
| BH12V190ZL-1 | 1160 | 1200 | 2950x2280x2069 | 9300 | ||
| BH12V190PZL-1 | 4189x2345x2636 | 11000 | ||||
| BH12V190ZL-2 | 960 | 1000 | 2950x2280x2069 | 9300 | ||
| BH12V190PZL-2 | 4189x2345x2636 | 11000 |
Technical Parameters
| Structure type | 4-stroke, direct injection combustion chamber, water-cooled, exhaust gas turbocharged, inlet air inter cooling | |
| Number and arrangement of cylinders | 12-cylinder V shape 60°angle | |
| Diameter of cylinders(mm) | 190 | |
| Stroke(mm) | 215 | |
| Total displacement(L) | 73.15 | |
| Compression ratio | 14.5:1 | |
| Exhaust temperature() | ≤650 | |
| Outlet temperature() | ≤90 | |
| Oil temperature(oil sump,) | ≤95 | |
| Steady speed change ratio (%) | ≤8(generator sets≤5) | |
| Cooling mode | Pressurized water cooling | |
| Lubrication mode | Press and spray lubrication | |
| Starting mode | Air motor or electric motor starting | |
