| In-line diesel engines | |||||||||
| Model | Rated Power(KW/hp) | Rated Speed(r/min) | Specific fuel consumption(g/kw.h) | Specific oil consumption(g/kw.h) | Overall Dimension L＊B＊H(mm) | Net weigh(KG) | |||
| 4190ZL | 330 | 1500 | ≤208 | ≤1.5 | 2290＊1240＊1750 | 3000 | |||
| 4190PZL | 330 | 1500 | ≤208 | ≤1.5 | 3119＊1370＊1896 | 3600 | |||
| 4190PZLG-1 | 270 | 1200 | ≤208 | ≤1.5 | 3119＊1370＊1896 | 3600 | |||
| 4190pzl-2 | 220 | 1000 | ≤208 | ≤1.5 | 3119＊1370＊1896 | 3600 | |||
| 4190PZLG-3 | 300 | 1300 | ≤208 | ≤1.5 | 3119＊1370＊1896 | 3600 | |||
| 6190ZL | 450 | 1500 | ≤204 | ≤1.5 | 2990＊1243＊1763 | 3960 | |||
| 6190PZL | 450 | 1500 | ≤204 | ≤1.5 | 3923＊1730＊2294 | 4600 | |||
| 6190ZL-2 | 330 | 1000 | ≤204 | ≤1.5 | 2990＊1243＊1763 | 3960 | |||
| 6190PZL-2 | 330 | 1000 | ≤204 | ≤1.5 | 3923＊1730＊2294 | 4600 | |||
| G6190ZL | 540 | 1500 | ≤204 | ≤1.5 | 2995*1295*1754 | 4500 | |||
| G6190PZL | 540 | 1500 | ≤204 | ≤1.5 | 3923*1730＊2294 | 5100 | |||
| 8190ZL | 720 | 1500 | ≤205 | ≤1.2 | 3175＊1208＊2055 | 5200 | |||
| Main technical data | |||||||||
| No. and arrangement of cylinders:12,60.Vee | |||||||||
| Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection | |||||||||
| Bore:190mm | |||||||||
| Stroke:210mm | |||||||||
| Total displacement:23.82/35.73/47.63L | |||||||||
| Compression ration:14:1/14.5:1 | |||||||||
| Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel) | |||||||||
| Starting method:Air motor or electric motor | |||||||||
|
Lubricating method:Pressure and splash lubrication Email:2239946438@qq.com |
|
|
|||||||
