8 in-line marine diesel engines |
||||||
| Model | Rated Power(kw/hp) | Rated speed(r/min) | Specific fuel consumption(g/kw’h) | Specific oil consumption(g/kw’h) | Overall dimension L*B*H(mm) | Net weight(kg) |
| 8190ZLCZ-R | 720/980 | 1450 | ≤ 204 | ≤ 1.2 | 3175*1220*2055 | 5200 |
| 8190ZLC | 720/980 | 1450 | ≤ 204 | ≤ 1.2 | 3175*1220*2055 | 5200 |
| 8190ZLCZ-1R | 600/820 | 1200 | ≤202 | ≤ 1.2 | 3175*1220*2055 | 5200 |
| 8190ZLCZ1-1R | 600/820 | 1200 | ≤202 | ≤ 1.2 | 3175*1220*2055 | 5200 |
| 8190ZLC-1 | 600/820 | 1200 | ≤202 | ≤ 1.2 | 3175*1220*2055 | 5200 |
| 8190ZLC1-1 | 600/820 | 1200 | ≤202 | ≤ 1.2 | 3175*1220*2055 | 5200 |
| 8190ZLCZ-2R | 500/680 | 1000 | ≤202 | ≤ 1.2 | 3175*1220*2055 | 5200 |
| 8190ZLC-2 | 500/680 | 1000 | ≤202 | ≤ 1.2 | 3175*1220*2055 | 5200 |
| 8190ZLCZ-3R | 650/880 | 1300 | ≤202 | ≤ 1.2 | 3175*1220*2055 | 5200 |
| 8190ZLC-3 | 650/880 | 1300 | ≤202 | ≤ 1.2 | 3175*1220*2055 | 5200 |
| Main technical data No. and arrangement of cylinders:8-cylinder,in-line Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection Bore:190mm Stroke:210mm Total displacement:47.6L Compression ration:14.5:1 Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel) Starting method:Air motor or electric motor Lubricating method:Pressure and splash lubrication |
||||||
